(24,214 actuations)
The Leica M8 Interchangeable Lens Rangefinder Digital Camera not only looks like an M model, it faithfully embodies all the advantages of the analog Leica M system to provide sophisticated and creative digital photography. It is the only professional digital camera to use the beneficial rangefinder system, which is discreet, quiet, fast and accurate, and the uncompromising quality criteria of the M system have been applied.
The Leica M8 provides full compatibility with almost all M lenses, and the low-noise CCD image sensor with a resolution of 10.3 million pixels has been specially integrated into the compact lens design, ensuring optimum picture quality. The operation and functionality of the digital M concentrate on what is essential, while useful additional functions provided by digital technology complement the proven M concept. The Leica M8 is a timeless digital camera that is excitingly new and yet comfortingly familiar.
Uses all Leica M Lenses
The Leica M lenses are recognized as the best in the world and demonstrate their full capabilities on the Leica M8. The extremely high resolution of all M system lenses since 1954 make them perfect for digital photography. The M8 quite deliberately has no resolution reducing moire filter in front of the sensor to maintain the full performance of the lens.
Supports M Lenses with 6 Bit-coding
The Leica M8 uses an optical scanner on the camera's bayonet to identify the 6 bit-coding of the current Leica M lenses. This allows the slight vignetting caused by the system to be compensated, further improving the familiar high image quality. The lens type identified is saved in the EXIF data for the image file and the reflector position on modern flash units is adjusted to the image angle depending on the focal length. Existing M lenses can be retroactively 6 bit-coded by the Leica Customer Service department.
Modified High Quality Image Sensor
The Kodak CCD technology used in the Leica M8 provides a high basic speed of ISO 160 extending to a maximum speed setting of ISO 2500, and produces pictures that rival the image quality of film-based Leica M cameras. A moire filter, which optically filters out fine image details, was deliberately omitted to utilize the full resolution of the Leica M lenses. Instead, any moire patterns are eliminated by the camera's signal processor. Because the light towards the edges impinges on the sensor obliquely with Leica M lenses, the thickness of the cover glass has been reduced to just 0.5 mm to prevent unwanted refraction. As a result, the image has uniform brightness right to the edge. To increase the light sensitivity of the CCD sensor, micro lenses are positioned in front of the pixels, and uses a special micro lens structure that is perfectly tailored to the characteristics of the Leica M lenses.10.3 Megapixel Resolution
The low-noise CCD image sensor has been optimized for the special features of the M lens system and provides an excellent resolution of 10.3 million pixels.Full Light Efficiency
The highest film speed settings of up to ISO 2500 allow much more detailed pictures to be taken than was ever possible with analog films. As a result, the M8 opens up a new chapter in the history of available light photography.
Durable Design
The Leica M8 is designed to deliver professional results over many years. The enclosed all-metal body is made of a high-strength magnesium alloy while the top and base plates are cut from solid brass blocks and then given a black or silver chrome finish. The battery and the SD card slot are located under the base plate and provides effective protection from dust and moisture.
Supports Creative Photography
The electronically controlled metal blade focal-plane shutter enables shutter speeds of up to 1/8000 second to be achieved. Even in very bright surroundings, the photographer still has total creative freedom thanks to the selective focus feature with open aperture. The high flash synchronization speed of 1/250 second now allows daylight flash photographs to be taken with selective focus.
Quiet and Discreet
To make cocking the shutter as close to silent as possible, a rubberized silent friction wheel has been placed in the first winding gear stage. A cam disk is used to transfer the force at a constant torque over the entire path of the cocking arm. As a result, the electric motor cocks the shutter almost soundlessly.
Optimum RAW Data Conversion
The professional Capture One LE RAW data converter ensures that the raw data supplied by the CCD sensor and saved in the future-proof Adobe digital negative format (DNG) is processed to yield optimum quality. Leica worked in conjunction with the Danish manufacturer Phase One to create the sophisticated camera profiling and the necessary software modifications. The results of this are quality-optimized algorithms for digital color processing, allowing exceptionally low-noise photography with incredible resolution. The development of even ultra fine tonal value nuances from the 16 bit-image supplied by the CCD sensor is comparable with the image quality provided by film professionally developed in a photographic laboratory. The logical functions for adjusting the quality and the well-structured user interface mean that Capture One LE can be used to achieve outstanding results with consummate ease and speed.
Simple, Intuitive Operation
Operation of the digital functions centers on the combined direction pad and dial, which can be used for fast navigation. Pressing the Set key opens the exposure parameter menu on the 2.5" monitor. Here, you can quickly check and adjust the crucial settings (Sensitivity, Exposure compensation, White balance, Data compression and Resolution). There are three blank slots in the memory for profiles, allowing you to retrieve frequently used combinations for specific applications. Pressing the Menu key takes you to the clearly structured system menu, where you can change some of the basic settings that are permanently applied, for example the ECI RGB, Adobe RGB and sRGB color space options. You can also specify whether you want your pictures to appear on the large display immediately to review them, how long they will be displayed for and whether a tonal value histogram appears. A display on the left-hand side of the top plate constantly shows the remaining capacity of the SD card and the lithium-ion battery. This elementary photographic information is thus available at a glance at all times.Innovative M-TTL Flash TechnologyThe unique feature of the Leica M-TTL flash technology is that a pre-flash for flash metering is fired immediately before the actual exposure. TTL measurement of the light reflected by the surfaces of the subject determines the exact power required from the main flash. The seamless addition of the flash intensity to the available light results in flash photographs that retain the natural lighting mood. The auto slow sync function allows you to use aperture priority mode in conjunction with the flash technology. It ensures that the image background is balanced even if the intensity of the ambient light should change. An appropriate metered amount of fill-in flash is emitted to provide correct exposure. Depending on the photographer's experience or the intended effect, various maximum exposure times can be set for aperture priority. This can be done manually or - when using 6 bit-coded lenses - automatically using the rule of thumb 1/focal length in seconds.
Sensor Cleaning Function
The LEICA M8 has a special function for manually cleaning the sensor. When you select the corresponding option in the menu and press the shutter release, the shutter remains open while cleaning is in progress. The low depth of the M camera makes the sensor more easily accessible than on digital reflex cameras, for example.
Tonal Value Histogram
As a professional digital camera, the LeicaM8 provides an RGB tonal value histogram. This can be called up at any time to check the exposure of saved pictures and can also be combined with the automatic review function. Another useful feature is the additional marking of overexposed sections of an image - known as the clipping warning. The particular advantage of this is that these two control tools are constantly updated constantly updated when zooming in on the LCD display, allowing the quality of even the finest image details to be assessed. Pressing the Info function key displays all of the photographic settings from the quick menu and additional meta-information saved with the image file - this enables you to completely evaluate a picture as soon as you have taken it.
Remote Control
The LEICA M8 is supplied with special software that allows the camera to be controlled remotely for scientific work or in a photographic studio. With Leica Digital Capture the camera can be operated from a computer via a USB connection and the image data can be saved directly onto hard disk. The software can send all settings in the exposure parameter menu, e. g. sensitivity and resolution, to the camera. The camera also has a traditional threaded release button for the use of a cable release.
