| Lens Mount |
Canon EF-S |
| Camera Format |
APS-C (1.6x Crop Factor) |
| Pixels |
Actual: 24.7 Megapixel
Effective: 24.1 Megapixel |
| Max Resolution |
6000 x 4000 |
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9 |
| Sensor Type / Size |
CMOS |
| File Formats |
Still Images: JPEG, RAW
Movies: MOV/H.264
Audio: Linear PCM |
| Bit Depth |
14-Bit |
| Memory Card Type |
SD
SDHC
SDXC (UHS-I) |
| Image Stabilisation |
None |
| Battery |
1x LP-E10 Rechargeable Lithium-Ion Battery Pack, 7.4 VDC, 860 mAh |
| Operating Temperature |
0 to 40°C |
| Self Timer |
2, 10 Seconds |
| Interval Recording |
Yes |
| Connectivity |
Canon E3, HDMI C (Mini), Micro-B (USB 2.0) |
| Wireless |
Wi-Fi |
| Built-in Flash |
Yes |
| Flash Modes |
Auto, Flash On, Off |
| Guide Number |
9.2m at ISO 100 |
| Max Sync Speed |
1 / 200 Second |
| Flash Compensation |
-2 EV to +2 EV (in 1/3,1/2 EV steps) |
| Dedicated Flash System |
eTTL |
| External Flash Connection |
Hot Shoe |
| Video Recording |
Yes, NTSC/PAL |
| Recording Limit |
Up to 29 Minutes, 59 Seconds for Full HD (1920 x 1080) |
| ISO Sensitivity |
100 to 12800 |
| Recording Modes |
MOV/H.264
Full HD (1920 x 1080) at 24.00p/25p/29.97p [46 Mb/s]
HD (1280 x 720) at 50p/59.94p [46 Mb/s]
SD (640 x 480) at 25p/29.94p [11
External Recording:
4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/29.97p
Full HD (1920 x 1080) at 59.94i/59.94p
SD (640 x 480) at 59.94p |
| Audio Recording |
Built-In Microphone (Stereo) |
| Focus Type |
Auto and Manual Focus |
| Focus Mode |
Manual Focus (M), Single-servo AF (S) |
| Autofocus Points |
Phase Detection: 9 (1 Cross-Type) |
| Autofocus Sensitivity |
0 to +18 EV |
| Viewfinder Type |
Optical (Pentamirror) |
| Viewfinder Coverage |
95% |
| Viewfinder Eyepoint |
21mm |
| Viewfinder Magnification |
Approx. 0.8x |
| Diopter Adjustment |
-2.5 to +0.5 |
| Display Screen |
3" Rear 920,000-Dot Fixed LCD |
| ISO Sensitivity |
Auto, 100 to 6400 (Extended Mode: 100 to 12800) |
| Shutter Speed |
1/4000 to 30 sec, Bulb Mode |
| Metering Modes |
Centre-Weighted Average, Evaluative, Partial |
| Exposure |
Modes: Aperture Priority, Manual, Program, Shutter Priority
Metering Range: 1 to 20.0 EV
Compensation: -5 to +5 EV (in 1/3, 1/2 EV Steps) |
| White Balance Modes |
Auto, Cloudy, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
| Buffer/Continous Shooting |
Up to 3 fps at 24 MP for up to 150 exposures in JPEG format/ 11 exposures in RAW format |
| Dimensions (W x H x D) |
129 x 101.3 x 77.6 mm |
| Weight |
475 g (with battery and memory card) |
